Description
MULTI PARAMETER PH-ORP-CONDUCTIVITY-TDS-SALINITY-RESISTIVITY-TEMP
|
| |
Labpro 902 water quality meter is designed for high performance and easy operation. The meter is capable of measuring up to 7 water quality parameters, including pH, ORP Conductivity, TDS, Salinity, Resistivity, and temperature, |
|
MULTI-POINT PUSH-BUTTON CALIBRATION |
| |
The meter has multi-point calibration mode. From setup menu, choose calibration and immerse electrode into indicated calibration solution, press ENTER key and meter is automatically calibrated. |
|
AUTO-BUFFER RECOGNITION |
| |
During calibration, if the calibration solution or selected value does not match the meter’s indicated value, an ERROR message is displayed. |
|
VIEWING OF ELECTRODE SLOPE |
| |
After calibration, the percentage slope of the electrode is displayed before the meter returns to measurement mode. Per the slope value, user decides whether to change the electrode |
|
AUTOMATIC TEMPERATURE COMPENSATION |
| |
By using temperature probe |
|
|
|
AUTO-RANGING FOR CONDUCTIVITY |
| |
The meter has auto-range functions for measuring conductivity and total dissolved solids (TDS). Upon immersing conductivity sensor into sample solution, the screen immediately displays the value in appropriate measurement range for accuracy, |
|
ADJUSTABLE TEMPERATURE COEFFICIENT |
| |
Various ions in solution have different temperature coefficients. LABMAN-LMMP30. can set the temperature coefficient between 0 and 3.9% in degrees centigrade for optimum accuracy |
|
ADJUSTABLE CELL CONSTANT |
| |
The meter has three cell constants for measuring requirements. Once a cell constant has its calibration set, it is saved and does not require re-calibration when switching meter |
|
MESSAGE INDICATOR |
| |
LABMAN-LMMP30 displays helpful messages like an on-screen manual for easy operation of this meter and selection of the various options |
|
SAVE AND COMMUNICATION INTERFACE |
| |
The meter all has real-time date/clock stamps. The memory stores up to 99 discrete data sets. Press the SAVE key to store the current measured values and it automatically generates a serial number with the date and time. This data can then be sent to a computer via the USB port |
|
|
| |
|
 |
| Model |
LMMP-902 |
| Make |
LABPRO |
| pH Range |
-2.000 to I6.000pH |
| pH Resolution |
±0.001pH |
| pH Accuracy |
±0.002pH |
| Calibration Points |
2 points, NIST(pH4.00/6.86/9.18) or USA(pH4.01/7.00/10.01] |
| mV/ORP Range |
0 to ±1999.9mV |
| mV/ORP Accuracy |
±0.2mV |
| Temperature Compensation |
0.0 to 100.0°C, Manual or Automatic |
| Conductivity Range |
0 to 1.999,19.99,199.9,1999 µ S, 19.99, 200.0mS |
| Conductivity Accuracy |
± 0.5% F.S |
| Calibration Points |
1 point per range |
| Temperature Compensation |
0 to 50°C, Manual or Automatic |
| Temperature Coefficient |
0 to 3.9% per°C |
| Cell Constant |
0.1,1.0,10 adjustable |
| TDS Range |
0 to 100 ppt, Max.200 ppt |
| TDS Accuracy |
+1% F.S |
| TDS Conversion Factor |
0.01 to 1.00, Default 0.67 |
| Salinity Range |
0 to 50 ppt, 0.00 to 5.00% |
| Accuracy |
±0.5ppt, ±0.05% |
| Resistivity Range and Accuracy |
0 to 100M, W± 1%F.S |
| Temperature Range |
0.0 to 100.0°C, |
| Temperature Accuracy |
±0.3°C, |
| Memory & Output |
99 data sets with date/ time stamping, USB |
| Power supply |
DC 9 V, using AC Adapter 220 VAC, 50 Hz |
| Weight |
1.75 kg |
|
