Pitot Tube Flow Measurement Setup

Description

Pitot tube set-up apparatus

Pitot tube set-up apparatus Experiments

To find the point velocity at the center of a tube for different flow rates of water and calibrate the Pitot Tube.
To plot velocity profile across the cross section of pipe
Utilities Required

Electric supply 0.5 kW, 220V AC, Single Phase
Water supply Tap water connection ” BSP Distilled water @ 60 liters (optional)
Floor Area with Drain facility
