Description
description The present set-up is designed to study Vertical condenser. It consists of a vertical condenser having a shell fitted with tubes. Cold fluid flows through inside the tubes and steam flows through the shell. Steam generator is fitted with heater to provide steam controlled by a Digital Temperature controller. Level indicator helps to maintain level of water in steam generator. Valves are provided to control the flow rates of cold fluids. Flow rate of cold water is measured using a Rotameter. Shell is fitted with steam traps from where condensate is collected in measuring cylinder. Temperature of inlet and outlet of both hot & cold fluids are measured by temperature sensors
